CY7C419-10JXC
RoHS
RoHS compliant
RoHS compliantPackage 32-LCC (J-Lead)
Category Integrated Circuits (ICs) / Logic - FIFOs Memory
Description
7C419 Depth Width Tube 8542.32.00.71 fifo memory 50MHz 85mA 1.27mm 20ns
PDF
/
Inventory: 5029
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 1.27mm
Frequency 50MHz
Time@Peak Reflow Temperature-Max (s) 20
Base Part Number 7C419
JESD-30 Code R-PQCC-J32
Function Asynchronous
Current - Supply (Max) 85mA
Operating Supply Voltage 5V
Power Supplies 5V
Memory Size 2.25K 256 x 9
Max Supply Current 85mA
Access Time 10ns
Organization 256X9
Memory Width 9
Standby Current-Max 0.005A
Memory Density 2304 bit
Parallel/Serial PARALLEL
Memory IC Type OTHER FIFO
Bus Directional Uni-Directional
Retransmit Capability Yes
Programmable Flags Support No
Output Enable NO
Expansion Type Depth, Width
Cycle Time 20 ns
Terminal Form J BEND
Terminal Position QUAD
Voltage - Supply 4.5V~5.5V
Technology CMOS
Subcategory FIFOs
HTS Code 8542.32.00.71
Additional Feature RETRANSMIT
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e3
Series CY7C
Published 2002
Packaging Tube
Operating Temperature 0°C~70°C
Dimensions
Height Seated (Max) 3.55mm
Length 13.97mm
Width 11.43mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Package / Case 32-LCC (J-Lead)
Mounting Type Surface Mount
Mount Surface Mount
