SNJ54S182FK

Texas Instruments
RoHS
/
Package /
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description TRUE QUAD TTL MIL-PRF-38535 logic counter 15pF 125C 99mA 5V
PDF
/
Inventory: 5050
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 week ago)

Physical

Surface Mount YES
Number of Pins 20

Technical

Number of Terminations 20
ECCN Code EAR99
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Additional Feature WITH HIGHER ORDER LOOKAHEAD
Subcategory Arithmetic Circuits
Packing Method TUBE
Technology TTL
Terminal Position QUAD
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 1.27mm
Pin Count 20
Operating Supply Voltage 5V
Temperature Grade MILITARY
Load Capacitance 15pF
Number of Bits 4
Family S
Output Polarity TRUE
Logic IC Type LOOK-AHEAD CARRY GENERATOR
Screening Level MIL-PRF-38535
Propagation Delay (tpd) 10.5 ns
Power Supply Current-Max (ICC) 99mA

Dimensions

Height 2.03mm
Length 8.89mm
Width 8.89mm
Thickness 1.83mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Contains Lead
