SN74LS593DWR
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
Tape & Reel (TR) Active e4 74LS593 logic counter 63ns 7.5mm 5V 0.024A
PDF
/
Buying Options
Total Price: USD $10.51
Unit Price: USD $10.5108
≥1 USD $10.5108
≥10 USD $8.6241
≥100 USD $8.35525
≥500 USD $8.08545
≥1000 USD $7.81565
Inventory: 1793
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295, 7.50mm Width)
Number of Pins 20
Weight 500.709277mg
Technical
Operating Temperature 0°C~70°C
Packaging Tape & Reel (TR)
Series 74LS
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature TCO OUTPUT; REGISTERED INPUTS; MULTIPLEXED I/O
Packing Method TR
Technology TTL
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Frequency 35MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 74LS593
Pin Count 20
Qualification Status Not Qualified
Operating Supply Voltage 5V
Number of Elements 1
Load Capacitance 45pF
Propagation Delay 63 ns
Reset Synchronous
Family LS
Logic Function Counter
Direction Up
Output Characteristics 3-STATE
Logic Type Binary Counter
Max I(ol) 0.024 A
Number of Bits per Element 8
Trigger Type Positive Edge
Clock Edge Trigger Type Positive Edge
Dimensions
Height 2.65mm
Length 12.8mm
Width 7.5mm
Thickness 2.35mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
