SN74LS590NSRE4
RoHS
/
Package SOP
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
Tape & Reel (TR) COMMERCIAL e4 Nickel/Palladium/Gold (Ni/Pd/Au) divider circuit 33ns 5.3mm 5V 0.024A
PDF
/
Inventory: 8552
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 5.3mm
Height Seated (Max) 2mm
Technical
Max Frequency@Nom-Sup 20000000Hz
Clock Edge Trigger Type Positive Edge
fmax-Min 20 MHz
Power Supply Current-Max (ICC) 65mA
Prop. Delay@Nom-Sup 33 ns
Max I(ol) 0.024 A
Output Characteristics 3-STATE
Direction Unidirectional
Logic Function Counter
Family LS
Reset Asynchronous
Propagation Delay 45 ns
Number of Bits 8
Load Capacitance 45pF
Min Supply Voltage 4.75V
Max Supply Voltage 5.25V
Temperature Grade COMMERCIAL
Power Supplies 5V
Number of Elements 1
Operating Supply Voltage 5V
Pin Count 16
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology TTL
Packing Method TAPE AND REEL
Additional Feature TCO OUTPUT; REGISTERED OUTPUTS
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Physical
Weight 200.686274mg
Number of Pins 16
Package / Case SOP
Mount Surface Mount
