SN74LS161AN3

Texas Instruments
RoHS
/
Package PDIP
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description PDIP COMMERCIAL Contains Lead RoHS Compliant divider circuit 35ns 7.62mm 5V 25MHz
PDF
/
Inventory: 3449
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status RoHS Compliant

Dimensions

Width 7.62mm
Length 19.305mm
Height Seated (Max) 5.08mm

Technical

Mode of Operation SYNCHRONOUS
Load/Preset Input YES
Count Direction UP
fmax-Min 25 MHz
Propagation Delay (tpd) 35 ns
Trigger Type POSITIVE EDGE
Logic IC Type BINARY COUNTER
Family LS
Number of Bits 4
Temperature Grade COMMERCIAL
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.25V
Operating Temperature (Max) 70°C
Qualification Status Not Qualified
Pin Count 16
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form THROUGH-HOLE
Terminal Position DUAL
Technology TTL
Subcategory Counters
Number of Terminations 16
Pbfree Code no

Physical

Number of Pins 16
Surface Mount NO
Package / Case PDIP
