SN74HC163DT
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
Tape & Reel (TR) Active e4 74HC163 logic counter 270ns 3.91mm 5V 0.0052A
PDF
/
Buying Options
Total Price: USD $1.11
Unit Price: USD $1.1088
≥1 USD $1.1088
≥10 USD $0.98824
≥100 USD $0.93808
≥500 USD $0.770704
Inventory: 1279
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Number of Pins 16
Weight 141.690917mg
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series 74HC
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature RCO OUTPUT
Packing Method TR
Technology CMOS
Voltage - Supply 2V~6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Frequency 44MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 74HC163
Pin Count 16
Qualification Status Not Qualified
Operating Supply Voltage 5V
Number of Elements 1
Supply Voltage-Max (Vsup) 6V
Power Supplies 2/6V
Supply Voltage-Min (Vsup) 2V
Load Capacitance 50pF
Propagation Delay 270 ns
Reset Synchronous
Family HC/UH
Logic Function Counter
Direction Up
Logic Type Binary Counter
Max I(ol) 0.0052 A
Number of Bits per Element 4
Trigger Type Positive Edge
Power Supply Current-Max (ICC) 0.08mA
fmax-Min 29 MHz
Clock Edge Trigger Type Positive Edge
Count Rate 36MHz
Dimensions
Height 1.75mm
Length 9.9mm
Width 3.91mm
Thickness 1.58mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
