SN74F169DRE4
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
GULL WING DUAL Positive Edge Synchronous Binary Counter IC 50pF 0C~70C 100MHz 0.02A
PDF
/
Inventory: 8894
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Number of Pins 16
Technical
Operating Temperature 0°C~70°C
Packaging Tape & Reel (TR)
Series 74F
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Additional Feature TCO OUTPUT
Packing Method TAPE AND REEL
Technology TTL
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Frequency 115MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 74F169
Pin Count 16
Qualification Status Not Qualified
Operating Supply Voltage 5.5V
Number of Elements 1
Power Supplies 5V
Load Capacitance 50pF
Family F/FAST
Logic Function Counter
Direction Up, Down
Logic Type Binary Counter
Max I(ol) 0.02 A
Number of Bits per Element 4
Trigger Type Positive Edge
Power Supply Current-Max (ICC) 52mA
fmax-Min 90 MHz
Clock Edge Trigger Type Positive Edge
Count Rate 100MHz
Load/Preset Input YES
Timing Synchronous
Dimensions
Length 9.9mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
