SN74AS280NE4
RoHS
/
Package PDIP
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
COMPLEMENTARY DUAL TTL AS divider circuit 70C -2mA 5V 7.62mm
PDF
/
Inventory: 1822
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Package / Case PDIP
Number of Pins 14
Weight 927.99329mg
Technical
Packaging Rail/Tube
JESD-609 Code e4
Pbfree Code yes
Number of Terminations 14
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Subcategory Arithmetic Circuits
Technology TTL
Terminal Position DUAL
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 2.54mm
Pin Count 14
Operating Supply Voltage 5V
Power Supplies 5V
Temperature Grade COMMERCIAL
Number of Circuits 1
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Current - Output 20mA
Number of Bits 9
Propagation Delay 12 ns
Turn On Delay Time 12 ns
Family AS
Logic Function Parity Gen
Output Characteristics 3-STATE
Output Polarity COMPLEMENTARY
High Level Output Current -2mA
Low Level Output Current 20mA
Dimensions
Height Seated (Max) 5.08mm
Width 7.62mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Contains Lead
