SN74AS163NSR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
GULL WING DUAL Positive Edge Synchronous Binary Counter IC 0C~70C 40MHz 0.02A 5.5V
PDF
/
Buying Options
Total Price: USD $2.76
Unit Price: USD $2.75975
≥1 USD $2.75975
≥10 USD $2.2648
≥100 USD $2.1945
≥500 USD $2.12325
≥1000 USD $2.05295
Inventory: 1324
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.209, 5.30mm Width)
Number of Pins 16
Weight 200.686274mg
Technical
Operating Temperature 0°C~70°C
Packaging Tape & Reel (TR)
Series 74AS
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Additional Feature TCO OUTPUT
Packing Method TAPE AND REEL
Technology TTL
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Frequency 75MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 74AS163
Pin Count 16
Qualification Status Not Qualified
Operating Supply Voltage 5.5V
Number of Elements 1
Power Supplies 5V
Reset Synchronous
Family AS
Logic Function Counter
Direction Up
Logic Type Binary Counter
Max I(ol) 0.02 A
Number of Bits per Element 4
Trigger Type Positive Edge
Power Supply Current-Max (ICC) 53mA
Clock Edge Trigger Type Positive Edge
Count Rate 40MHz
Dimensions
Height Seated (Max) 2mm
Width 5.3mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
