M38510/38003BEA
RoHS
/
Package CDIP
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
DUAL POSITIVE EDGE Qualified TTL logic counter 125C 25MHz 0.008A 5V
PDF
/
Inventory: 986
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Dimensions
Thickness 4.57mm
Width 6.92mm
Length 19.56mm
Height 5.08mm
Technical
Mode of Operation SYNCHRONOUS
Load/Preset Input YES
fmax-Min 25 MHz
Power Supply Current-Max (ICC) 25mA
Trigger Type POSITIVE EDGE
Screening Level MIL-PRF-38535
Prop. Delay@Nom-Sup 20 ns
Max I(ol) 0.008 A
Direction Bidirectional
Logic Function Counter
Family ALS
Propagation Delay 26 ns
Number of Bits 4
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Temperature Grade MILITARY
Power Supplies 5V
Number of Elements 1
Operating Supply Voltage 5V
Qualification Status Qualified
Pin Count 16
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology TTL
Min Operating Temperature -55°C
Max Operating Temperature 125°C
ECCN Code EAR99
Number of Terminations 16
Packaging Rail/Tube
Physical
Number of Pins 16
Package / Case CDIP
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
