CY74FCT191CTSOCT
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
Tape & Reel (TR) Obsolete 74FCT191 TCO OUTPUT divider circuit 6.2ns 7.5mm 5V -40C~85C
PDF
/
Buying Options
Total Price: USD $0.5
Unit Price: USD $0.5016
≥1 USD $0.5016
Inventory: 9386
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Height Seated (Max) 2.65mm
Technical
Timing Synchronous
Load/Preset Input YES
Clock Edge Trigger Type Positive Edge
Trigger Type Positive Edge
Prop. Delay@Nom-Sup 6.2 ns
Number of Bits per Element 4
Logic Type Binary Counter
Output Characteristics 3-STATE
Direction Up, Down
Logic Function Counter
Family FCT
Propagation Delay 11 ns
Load Capacitance 50pF
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.25V
Number of Elements 1
Qualification Status Not Qualified
Pin Count 16
Base Part Number 74FCT191
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology CMOS
Packing Method TAPE AND REEL
Additional Feature TCO OUTPUT
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Series 74FCT
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 420.395078mg
Number of Pins 16
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
