CY74FCT191ATSOCT
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
GULL WING DUAL Positive Edge Synchronous Binary Counter IC 50pF -40C~85C 5.25V 7.5mm
PDF
/
Inventory: 2214
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295, 7.50mm Width)
Number of Pins 16
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series 74FCT
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Additional Feature TCO OUTPUT
Packing Method TAPE AND REEL
Technology CMOS
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 74FCT191
Pin Count 16
Qualification Status Not Qualified
Operating Supply Voltage 5.25V
Number of Elements 1
Power Supplies 5V
Load Capacitance 50pF
Family FCT
Logic Function Counter
Direction Up, Down
Output Characteristics 3-STATE
Logic Type Binary Counter
Number of Bits per Element 4
Prop. Delay@Nom-Sup 7.8 ns
Trigger Type Positive Edge
Propagation Delay (tpd) 7.8 ns
Clock Edge Trigger Type Positive Edge
Load/Preset Input YES
Timing Synchronous
Dimensions
Height Seated (Max) 2.65mm
Width 7.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
