CD74HC93M96
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
GULL WING DUAL Negative Edge Asynchronous Binary Counter IC 50pF -55C~125C 35MHz 0.0052A
PDF
/
Buying Options
Total Price: USD $1.41
Unit Price: USD $1.408
≥1 USD $1.408
≥10 USD $1.25576
≥100 USD $1.192224
≥500 USD $0.979176
≥1000 USD $0.915341
≥3000 USD $0.808896
Inventory: 1622
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Number of Pins 14
Weight 129.387224mg
Technical
Operating Temperature -55°C~125°C
Packaging Cut Tape (CT)
Series 74HC
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Packing Method TR
Technology CMOS
Voltage - Supply 2V~6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 4.5V
Frequency 35MHz
Base Part Number 74HC93
Pin Count 14
Number of Elements 1
Supply Voltage-Max (Vsup) 6V
Power Supplies 2/6V
Supply Voltage-Min (Vsup) 2V
Load Capacitance 50pF
Propagation Delay 370 ns
Quiescent Current 8μA
Turn On Delay Time 370 ns
Reset Asynchronous
Family HC/UH
Logic Function Counter
Direction Up
Logic Type Binary Counter
Max I(ol) 0.0052 A
Number of Bits per Element 4
Prop. Delay@Nom-Sup 52 ns
Trigger Type Negative Edge
Power Supply Current-Max (ICC) 0.08mA
Clock Edge Trigger Type Negative Edge
Dimensions
Height 1.75mm
Length 8.65mm
Width 3.91mm
Thickness 1.58mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
