CD4522BPWRE4
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
GULL WING DUAL Positive Negative Asynchronous Divide-by-N IC 50pF -55C~125C 8MHz 18V
PDF
/
Inventory: 8157
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 5mm
Technical
Count Rate 8MHz
Trigger Type Positive, Negative
Number of Bits per Element 4
Logic Type Divide-by-N
Direction Down
Reset Asynchronous
Load Capacitance 50pF
Supply Voltage-Min (Vsup) 3V
Number of Elements 1
Operating Supply Voltage 18V
Qualification Status Not Qualified
Pin Count 16
Base Part Number CD4522
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~18V
Technology CMOS
Packing Method TAPE AND REEL
Subcategory Counters
Additional Feature DUMMY VAL
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series 4000B
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Number of Pins 16
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
