CD4522BNSRG4
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
GULL WING DUAL Positive Negative Asynchronous Divide-by-N IC 50pF -55C~125C 8MHz 18V
PDF
/
Inventory: 1533
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.209, 5.30mm Width)
Number of Pins 16
Weight 200.686274mg
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series 4000B
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Additional Feature DUMMY VAL
Subcategory Counters
Packing Method TAPE AND REEL
Technology CMOS
Voltage - Supply 3V~18V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Frequency 8MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number CD4522
Pin Count 16
Qualification Status Not Qualified
Operating Supply Voltage 18V
Number of Elements 1
Supply Voltage-Min (Vsup) 3V
Load Capacitance 50pF
Reset Asynchronous
Direction Down
Logic Type Divide-by-N
Number of Bits per Element 4
Trigger Type Positive, Negative
Dimensions
Height Seated (Max) 2mm
Width 5.3mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
