CD4521BPWR
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
GULL WING DUAL Negative Edge Asynchronous Divide-by-2 IC 50pF -55C~125C 2000000Hz 18V
PDF
/
Inventory: 3068
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Number of Pins 16
Weight 172.98879mg
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series 4000B
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Additional Feature OUTPUTS FROM LAST 7 STAGES AVAILABLE
Subcategory Counters
Packing Method TAPE AND REEL
Technology CMOS
Voltage - Supply 3V~18V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number CD4521
Pin Count 16
Qualification Status Not Qualified
Operating Supply Voltage 18V
Number of Elements 1
Supply Voltage-Min (Vsup) 3V
Load Capacitance 50pF
Reset Asynchronous
Logic Type Divide-by-2
Number of Bits per Element 24
Trigger Type Negative Edge
fmax-Min 6.5 MHz
Count Direction UP
Clock Edge Trigger Type Negative Edge
Max Frequency@Nom-Sup 2000000Hz
Count Rate 13MHz
Dimensions
Length 5mm
Width 4.4mm
Compliance
RoHS Status ROHS3 Compliant
