CD4518BPWG4
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
Tube Active e4 CD4518 logic counter 650ns 4.4mm 5/15V 0.0015A
PDF
/
Buying Options
Total Price: USD $1.4
Unit Price: USD $1.395613
≥1 USD $1.395613
≥180 USD $0.55667
≥540 USD $0.538289
≥990 USD $0.529099
Inventory: 907
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1mm
Width 4.4mm
Length 5mm
Height 1.2mm
Technical
Timing Synchronous
Power Supply Current-Max (ICC) 0.03mA
Trigger Type Positive, Negative
Number of Bits per Element 4
Max I(ol) 0.0015 A
Logic Type BCD Counter
Direction Up
Logic Function Counter
Reset Asynchronous
Turn On Delay Time 650 ns
Quiescent Current 100μA
Propagation Delay 650 ns
Load Capacitance 50pF
Supply Voltage-Min (Vsup) 3V
Power Supplies 5/15V
Supply Voltage-Max (Vsup) 18V
Number of Elements 2
Qualification Status Not Qualified
Pin Count 16
Base Part Number CD4518
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 8MHz
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~18V
Technology CMOS
Additional Feature GATED CLOCK; SCHMITT TRIGGER ON CLOCK INPUT
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 4000B
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Weight 61.887009mg
Number of Pins 16
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
