CD4518BF3A
RoHS
/
Package CDIP
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
DUAL POSITIVE EDGE CMOS Unidirectional logic counter 50pF 125C 1500000Hz 0.0015A
PDF
/
Buying Options
Total Price: USD $11.08
Unit Price: USD $11.084749
≥1 USD $11.084749
≥10 USD $10.457308
≥100 USD $9.865388
≥500 USD $9.30697
≥1000 USD $8.780156
Inventory: 2067
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Thickness 4.57mm
Width 6.92mm
Length 19.56mm
Height 5.08mm
Technical
Load/Preset Input NO
Max Frequency@Nom-Sup 1500000Hz
Power Supply Current-Max (ICC) 0.03mA
Trigger Type POSITIVE EDGE
Max I(ol) 0.0015 A
Direction Unidirectional
Logic Function Counter
Turn On Delay Time 650 ns
Quiescent Current 100μA
Propagation Delay 650 ns
Number of Bits 4
Load Capacitance 50pF
Min Supply Voltage 3V
Max Supply Voltage 18V
Temperature Grade MILITARY
Power Supplies 5/15V
Number of Elements 2
Pin Count 16
Supply Voltage 5V
Number of Functions 2
Terminal Position DUAL
Technology CMOS
Packing Method TUBE
Additional Feature GATED CLOCK; SCHMITT TRIGGER ON CLOCK INPUT
Min Operating Temperature -55°C
Max Operating Temperature 125°C
ECCN Code EAR99
Number of Terminations 16
Physical
Number of Pins 16
Package / Case CDIP
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
