CD4516BNS
RoHS
/
Package SOP
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
GULL WING DUAL POSITIVE EDGE BIDIRECTIONAL divider circuit 50pF 125C 2000000Hz 0.0015A
PDF
/
Inventory: 2936
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case SOP
Surface Mount YES
Number of Pins 16
Technical
JESD-609 Code e4
Pbfree Code yes
Moisture Sensitivity Level (MSL) 1
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature TCO OUTPUT
Subcategory Counters
Packing Method TR
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 16
Qualification Status Not Qualified
Operating Temperature (Max) 125°C
Operating Temperature (Min) -55°C
Supply Voltage-Max (Vsup) 18V
Power Supplies 5/15V
Temperature Grade MILITARY
Supply Voltage-Min (Vsup) 3V
Load Capacitance 50pF
Number of Bits 4
Logic IC Type BINARY COUNTER
Max I(ol) 0.0015 A
Prop. Delay@Nom-Sup 200 ns
Trigger Type POSITIVE EDGE
Power Supply Current-Max (ICC) 0.03mA
fmax-Min 5.5 MHz
Count Direction BIDIRECTIONAL
Max Frequency@Nom-Sup 2000000Hz
Load/Preset Input YES
Mode of Operation SYNCHRONOUS
Dimensions
Height Seated (Max) 2mm
Length 10.3mm
Width 5.3mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
