CD4045BPWR
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
Cut Tape (CT) Obsolete e4 CD4045 logic counter 5.5mus 4.4mm 5V 12MHz
PDF
/
Inventory: 7927
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4.4mm
Length 5mm
Technical
Load/Preset Input YES
Count Rate 12MHz
Clock Edge Trigger Type Negative Edge
fmax-Min 45 MHz
Trigger Type Negative Edge
Number of Bits per Element 21
Logic Type Binary Counter
Direction Up
Logic Function Counter
Propagation Delay 5.5 μs
Load Capacitance 50pF
Supply Voltage-Min (Vsup) 3V
Number of Elements 1
Pin Count 16
Base Part Number CD4045
Frequency 30MHz
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~18V
Technology CMOS
Packing Method TAPE AND REEL
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series 4000B
Packaging Cut Tape (CT)
Operating Temperature -55°C~125°C
Physical
Weight 61.887009mg
Number of Pins 16
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
