CD4045BNSRE4
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
GULL WING DUAL Negative Edge Not Qualified Binary Counter IC 50pF -55C~125C 5000000Hz 18V
PDF
/
Inventory: 3768
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.209, 5.30mm Width)
Number of Pins 16
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series 4000B
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Packing Method TAPE AND REEL
Technology CMOS
Voltage - Supply 3V~18V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number CD4045
Pin Count 16
Qualification Status Not Qualified
Operating Supply Voltage 18V
Number of Elements 1
Supply Voltage-Min (Vsup) 3V
Load Capacitance 50pF
Logic Function Counter
Direction Up
Logic Type Binary Counter
Number of Bits per Element 21
Trigger Type Negative Edge
Propagation Delay (tpd) 5500 ns
fmax-Min 45 MHz
Clock Edge Trigger Type Negative Edge
Max Frequency@Nom-Sup 5000000Hz
Count Rate 12MHz
Load/Preset Input YES
Mode of Operation SYNCHRONOUS
Dimensions
Height Seated (Max) 2mm
Width 5.3mm
Compliance
RoHS Status ROHS3 Compliant
