CD4033BNSRE4

Texas Instruments
RoHS
RoHS RoHS compliant
Package 16-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description GULL WING DUAL Positive Edge Asynchronous divider circuit -55C~125C 16MHz 18V 2mm
PDF
/
Inventory: 7113
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height Seated (Max) 2mm

Technical

Timing Synchronous
Count Rate 16MHz
Clock Edge Trigger Type Positive Edge
fmax-Min 8 MHz
Trigger Type Positive Edge
Number of Bits per Element 5
Logic Type Counter, Decade
Direction Up
Logic Function Counter
Reset Asynchronous
Number of Bits 7
Supply Voltage-Min (Vsup) 3V
Number of Elements 1
Operating Supply Voltage 18V
Qualification Status Not Qualified
Pin Count 16
Base Part Number CD4033
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~18V
Technology CMOS
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series 4000B
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C

Physical

Number of Pins 16
Package / Case 16-SOIC (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
