CD4024BPWRG4
RoHS
/
Package TSSOP
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
Tape & Reel (TR) MILITARY e4 Nickel/Palladium/Gold (Ni/Pd/Au) logic counter 360ns 4.4mm 18V 24MHz
PDF
/
Inventory: 942
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 4.4mm
Length 5mm
Technical
Clock Edge Trigger Type Negative Edge
Number of Bits per Element 7
Direction Unidirectional
Logic Function Counter
Reset Asynchronous
Turn On Delay Time 360 ns
Propagation Delay 360 ns
Number of Bits 12
Load Capacitance 50pF
Min Supply Voltage 3V
Max Supply Voltage 18V
Temperature Grade MILITARY
Number of Elements 1
Pin Count 14
Frequency 24MHz
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Packing Method TAPE AND REEL
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Physical
Weight 57.209338mg
Number of Pins 14
Package / Case TSSOP
Mount Surface Mount
