CD4024BNSR
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
Tape & Reel (TR) Active e4 CD4024 divider circuit 360ns 5.3mm 5V 0.03mA
PDF
/
Buying Options
Total Price: USD $0.8
Unit Price: USD $0.8008
≥1 USD $0.8008
≥10 USD $0.70664
≥100 USD $0.663872
≥500 USD $0.541904
≥1000 USD $0.50336
≥3000 USD $0.428402
Inventory: 1119
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1.95mm
Width 5.3mm
Length 10.3mm
Height 2mm
Technical
Clock Edge Trigger Type Negative Edge
Power Supply Current-Max (ICC) 0.03mA
Trigger Type Negative Edge
Number of Bits per Element 7
Logic Type Binary Counter
Direction Up
Logic Function Counter
Reset Asynchronous
Quiescent Current 100μA
Propagation Delay 360 ns
Number of Bits 12
Load Capacitance 50pF
Supply Voltage-Min (Vsup) 3V
Number of Elements 1
Qualification Status Not Qualified
Pin Count 14
Base Part Number CD4024
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 24MHz
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~18V
Technology CMOS
Packing Method TR
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 4000B
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Weight 208.312296mg
Number of Pins 14
Package / Case 14-SOIC (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
