CD4022BNSR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
Cut Tape (CT) Active e4 CD4022 logic counter 270ns 5.3mm 5V 0.03mA
PDF
/
Buying Options
Total Price: USD $1.02
Unit Price: USD $1.0208
≥1 USD $1.0208
≥10 USD $0.9152
≥100 USD $0.868384
≥500 USD $0.713416
≥1000 USD $0.666899
≥3000 USD $0.589371
Inventory: 1164
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.95mm
Width 5.3mm
Length 10.3mm
Height 2mm
Technical
Count Rate 6MHz
Clock Edge Trigger Type Positive Edge
fmax-Min 5.5 MHz
Power Supply Current-Max (ICC) 0.03mA
Trigger Type Positive Edge
Prop. Delay@Nom-Sup 270 ns
Number of Bits per Element 4
Logic Type Binary Counter
Direction Up
Logic Function Counter
Reset Asynchronous
Turn On Delay Time 650 ns
Quiescent Current 100μA
Propagation Delay 650 ns
Number of Bits 10
Load Capacitance 50pF
Supply Voltage-Min (Vsup) 3V
Number of Elements 1
Pin Count 16
Base Part Number CD4022
Frequency 11MHz
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~18V
Technology CMOS
Packing Method TR
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 4000B
Packaging Cut Tape (CT)
Operating Temperature -55°C~125°C
Physical
Weight 200.686274mg
Number of Pins 16
Package / Case 16-SOIC (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
