CD4018BPWRE4
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
GULL WING DUAL Positive Edge Asynchronous Divide-by-N IC -55C~125C 8.5MHz 18V 4.4mm
PDF
/
Inventory: 6459
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 4.4mm
Technical
Timing Synchronous
Count Rate 8.5MHz
Clock Edge Trigger Type Positive Edge
Count Direction UP
Propagation Delay (tpd) 400 ns
Trigger Type Positive Edge
Number of Bits per Element 5
Logic Type Divide-by-N
Reset Asynchronous
Supply Voltage-Min (Vsup) 3V
Number of Elements 1
Operating Supply Voltage 18V
Qualification Status Not Qualified
Pin Count 16
Base Part Number CD4018
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 17MHz
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~18V
Technology CMOS
Packing Method TAPE AND REEL
Subcategory Counters
Additional Feature JOHNSON COUNTER, PROGRAMMABLE WITH EXT CONNECTION
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series 4000B
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Number of Pins 16
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
