CD4017BNSRE4
RoHS
/
Package SOP
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
Tape & Reel (TR) MILITARY e4 Nickel/Palladium/Gold (Ni/Pd/Au) divider circuit 650ns 5.3mm 18V 11MHz
PDF
/
Inventory: 5270
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case SOP
Number of Pins 16
Weight 200.686274mg
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Moisture Sensitivity Level (MSL) 1
Number of Terminations 16
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Packing Method TAPE AND REEL
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Frequency 11MHz
Pin Count 16
Number of Elements 1
Temperature Grade MILITARY
Max Supply Voltage 18V
Min Supply Voltage 3V
Load Capacitance 50pF
Number of Bits 10
Propagation Delay 650 ns
Reset Asynchronous
Logic Function Counter
Direction Unidirectional
Sync/Async Synchronous
fmax-Min 5.5 MHz
Clock Edge Trigger Type Positive Edge
Dimensions
Height Seated (Max) 2mm
Width 5.3mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Contains Lead
