CD4017BM96
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
Tape & Reel (TR) Active e4 CD4017 divider circuit 270ns 3.91mm 5V 100muA
PDF
/
Buying Options
Total Price: USD $0.47
Unit Price: USD $0.4664
≥1 USD $0.4664
≥10 USD $0.39952
≥100 USD $0.37312
≥500 USD $0.298672
≥1000 USD $0.277306
≥3000 USD $0.234643
Inventory: 3991
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 9.9mm
Height 1.75mm
Technical
Timing Synchronous
Count Rate 5.5MHz
Ambient Temperature Range High 125°C
Clock Edge Trigger Type Positive Edge
fmax-Min 5.5 MHz
Trigger Type Positive Edge
Prop. Delay@Nom-Sup 270 ns
Number of Bits per Element 10
Logic Type Counter, Decade
Direction Up
Number of Inputs 3
Logic Function Counter
Reset Asynchronous
Turn On Delay Time 650 ns
Quiescent Current 100μA
Propagation Delay 85 ns
Load Capacitance 50pF
Supply Voltage-Min (Vsup) 3V
Number of Elements 1
Pin Count 16
Base Part Number CD4017
Frequency 11MHz
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~18V
Technology CMOS
Packing Method TR
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 4000B
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Weight 141.690917mg
Number of Pins 16
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
