83022022A
RoHS
/
Package /
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
TUBE MILITARY TCO OUTPUT Counter logic counter 25ns 8.89mm 5V 0.008A
PDF
/
Buying Options
Total Price: USD $27.44
Unit Price: USD $27.4384
≥1 USD $27.4384
Inventory: 139
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Thickness 1.83mm
Width 8.89mm
Length 8.89mm
Height 2.03mm
Technical
Load/Preset Input YES
Max Frequency@Nom-Sup 35000000Hz
fmax-Min 22 MHz
Trigger Type POSITIVE EDGE
Screening Level MIL-STD-883
Max I(ol) 0.008 A
Direction Unidirectional
Logic Function Counter
Family ALS
Turn On Delay Time 25 ns
Propagation Delay 25 ns
Number of Bits 4
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Temperature Grade MILITARY
Power Supplies 5V
Number of Elements 1
Operating Supply Voltage 5V
Qualification Status Qualified
Pin Count 20
Supply Voltage 5V
Number of Functions 1
Terminal Position QUAD
Technology TTL
Packing Method TUBE
Additional Feature TCO OUTPUT
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Terminations 20
Physical
Number of Pins 20
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
