T74LS393M
RoHS
/
Package /
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
GULL WING DUAL NEGATIVE EDGE UP divider circuit 15pF 70C 25000000Hz 0.008A
PDF
/
Inventory: 3282
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Surface Mount YES
Technical
JESD-609 Code e0
Number of Terminations 14
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8542.39.00.01
Subcategory Counters
Technology TTL
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 2
Supply Voltage 5V
Terminal Pitch 1.27mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 14
JESD-30 Code R-PDSO-G14
Qualification Status Not Qualified
Operating Temperature (Max) 70°C
Supply Voltage-Max (Vsup) 5.25V
Power Supplies 5V
Temperature Grade COMMERCIAL
Supply Voltage-Min (Vsup) 4.75V
Load Capacitance 15pF
Number of Bits 4
Family LS
Logic IC Type BINARY COUNTER
Max I(ol) 0.008 A
Trigger Type NEGATIVE EDGE
Propagation Delay (tpd) 60 ns
Power Supply Current-Max (ICC) 30mA
fmax-Min 25 MHz
Count Direction UP
Max Frequency@Nom-Sup 25000000Hz
Load/Preset Input NO
Mode of Operation ASYNCHRONOUS
Dimensions
Height Seated (Max) 1.75mm
Length 8.65mm
Width 3.9mm
Compliance
RoHS Status Non-RoHS Compliant
