M74HC4017M1R
RoHS
/
Package SO
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
GULL WING DUAL POSITIVE EDGE UP logic counter 50pF 125C 20000000Hz 0.004A
PDF
/
Inventory: 3519
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 3.9mm
Length 9.9mm
Technical
Mode of Operation SYNCHRONOUS
Load/Preset Input NO
Max Frequency@Nom-Sup 20000000Hz
Count Direction UP
fmax-Min 20 MHz
Number of Output Lines 10
Number of Input Lines 1
Trigger Type POSITIVE EDGE
Max I(ol) 0.004 A
Logic Function Counter
Family HC/UH
Propagation Delay 33 ns
Number of Bits 10
Load Capacitance 50pF
Max Supply Voltage 6V
Supply Voltage-Min (Vsup) 2V
Temperature Grade MILITARY
Operating Supply Voltage 5V
Qualification Status Not Qualified
Pin Count 16
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 4.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3
JESD-609 Code e4
Physical
Surface Mount YES
Package / Case SO
