M74HC161TTR
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
Tape & Reel (TR) Obsolete e4 M74HC161 logic counter 21ns 5mm 2/6V 62MHz
PDF
/
Inventory: 5591
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Number of Pins 16
Weight 172.98879mg
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series 74HC
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature TCO OUTPUT
Packing Method TAPE AND REEL
Technology CMOS
Voltage - Supply 2V~6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 4.5V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number M74HC161
Pin Count 16
Number of Elements 1
Supply Voltage-Max (Vsup) 6V
Power Supplies 2/6V
Supply Voltage-Min (Vsup) 2V
Load Capacitance 50pF
Number of Bits 4
Propagation Delay 21 ns
Turn On Delay Time 300 ns
Reset Asynchronous
Family HC/UH
Logic Function Counter
Direction Up
Logic Type Binary Counter
Trigger Type Positive Edge
Number of Input Lines 4
fmax-Min 25 MHz
Clock Edge Trigger Type Positive Edge
Count Rate 62MHz
Timing Synchronous
Dimensions
Length 5mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
