HCF4017BEY
RoHS
RoHS compliant
RoHS compliantPackage 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
Tube Obsolete e4 HCF4017 divider circuit 650ns 7.1mm 18V 11MHz
PDF
/
Buying Options
Total Price: USD $0.49
Unit Price: USD $0.48545
≥1 USD $0.48545
≥10 USD $0.399
≥100 USD $0.38665
≥500 USD $0.3743
≥1000 USD $0.361
Inventory: 1697
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 16-DIP (0.300, 7.62mm)
Number of Pins 16
Weight 1.627801g
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Series 4000B
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Technology CMOS
Voltage - Supply 3V~20V
Terminal Position DUAL
Number of Functions 1
Supply Voltage 5V
Frequency 11MHz
Base Part Number HCF4017
Pin Count 16
Operating Supply Voltage 18V
Supply Voltage-Max (Vsup) 20V
Supply Voltage-Min (Vsup) 3V
Number of Bits 5
Propagation Delay 650 ns
Turn On Delay Time 650 ns
Reset Asynchronous
Logic Function Counter
Direction Up
Logic Type Counter, Decade
Number of Bits per Element 10
Trigger Type Positive Edge
Number of Input Lines 1
Clock Edge Trigger Type Positive Edge
Dimensions
Height 5.1mm
Length 20mm
Width 7.1mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
