74AC161TTR
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
Cut Tape (CT) MILITARY Obsolete e4 divider circuit 9ns 5mm 3.3/5V 60000000Hz
PDF
/
Inventory: 2461
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 5mm
Technical
Max Frequency@Nom-Sup 60000000Hz
Clock Edge Trigger Type Positive Edge
fmax-Min 95 MHz
Number of Input Lines 4
Sync/Async Synchronous
Trigger Type Positive Edge
Logic Type Binary Counter
Direction Up
Logic Function Counter
Family AC
Reset Asynchronous
Propagation Delay 9 ns
Number of Bits 4
Load Capacitance 50pF
Supply Voltage-Min (Vsup) 2V
Temperature Grade MILITARY
Power Supplies 3.3/5V
Supply Voltage-Max (Vsup) 6V
Number of Elements 1
Qualification Status Not Qualified
Pin Count 16
Base Part Number 74AC161
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~6V
Technology CMOS
Packing Method TAPE AND REEL
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Series 74AC
Packaging Cut Tape (CT)
Physical
Number of Pins 16
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
