SN74LS193N
RoHS
/
Package 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
DUAL Positive Edge Asynchronous Synchronous Binary Counter IC 0C~70C 32MHz 5V 7.62mm
PDF
/
Buying Options
Total Price: USD $0.53
Unit Price: USD $0.528
≥1 USD $0.528
Inventory: 1810
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 7.62mm
Technical
Timing Synchronous
Count Rate 32MHz
fmax-Min 25 MHz
Trigger Type Positive Edge
Number of Bits per Element 4
Logic Type Binary Counter
Direction Up, Down
Family LS
Reset Asynchronous
Supply Voltage-Max (Vsup) 5.25V
Number of Elements 1
Qualification Status Not Qualified
Pin Count 16
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology TTL
Terminal Finish TIN LEAD
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Series 74LS
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Surface Mount NO
Package / Case 16-DIP (0.300, 7.62mm)
Mounting Type Through Hole
