SN74HC4020DT image
Favorite
SN74HC4020DT image
Favorite
RoHS
RoHS RoHS compliant
Package 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description GULL WING DUAL Negative Edge Asynchronous Binary Counter IC -40C~85C 33MHz 5V 3.9mm
PDF
/
Buying Options
Total Price: USD $2.68
Unit Price: USD $2.6847
≥1 USD $2.6847
≥10 USD $2.20305
≥100 USD $2.13465
≥500 USD $2.0653
≥1000 USD $1.9969
Inventory: 20002
Minimum: 1
-
+

Technical Details

Technical

Number of Bits per Element 14
Trigger Type Negative Edge
fmax-Min 25 MHz
Count Rate 33MHz
Logic Type Binary Counter
Direction Up
Family HC/UH
Reset Asynchronous
Supply Voltage-Min (Vsup) 2V
Supply Voltage-Max (Vsup) 6V
Number of Elements 1
Supply Voltage 5V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~6V
Technology CMOS
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series 74HC
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C

Dimensions

Length 9.9mm
Width 3.9mm

Compliance

RoHS Status ROHS3 Compliant

Physical

Surface Mount YES
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
