SN74ALS869NT
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
DUAL Positive Edge Synchronous COMMERCIAL Binary Counter IC 0C~70C 35MHz 5V 7.62mm
PDF
/
Buying Options
Total Price: USD $7.54
Unit Price: USD $7.54205
≥1 USD $7.54205
≥10 USD $6.1883
≥100 USD $5.99545
≥500 USD $5.80165
≥1000 USD $5.6088
Inventory: 9306
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.62mm
Technical
Count Rate 35MHz
fmax-Min 35 MHz
Trigger Type Positive Edge
Number of Bits per Element 8
Logic Type Binary Counter
Direction Up, Down
Family ALS
Reset Synchronous
Supply Voltage-Min (Vsup) 4.5V
Supply Voltage-Max (Vsup) 5.5V
Number of Elements 1
Qualification Status COMMERCIAL
JESD-30 Code R-PDIP-T24
Pin Count 24
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology TTL
Additional Feature TCO OUTPUT; COUNT ENABLE INPUTS
Terminal Finish NICKEL PALLADIUM GOLD
Number of Terminations 24
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series 74ALS
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Surface Mount NO
Package / Case 24-DIP (0.300, 7.62mm)
Mounting Type Through Hole
