MC74HC4040AD
RoHS
/
Package 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
Tube Obsolete e4 NICKEL PALLADIUM GOLD divider circuit 4.4mm 3V 50MHz -55C~125C
PDF
/
Buying Options
Total Price: USD $0.09
Unit Price: USD $0.088
≥1 USD $0.088
Inventory: 1123
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Series 74HC
JESD-609 Code e4
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Terminal Finish NICKEL PALLADIUM GOLD
Technology CMOS
Voltage - Supply 2V~6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 40
Pin Count 16
Qualification Status COMMERCIAL
Number of Elements 1
Supply Voltage-Max (Vsup) 6V
Supply Voltage-Min (Vsup) 2V
Reset Asynchronous
Family HC/UH
Direction Up
Logic Type Binary Counter
Number of Bits per Element 12
Trigger Type Negative Edge
fmax-Min 40 MHz
Count Rate 50MHz
Dimensions
Length 5mm
Width 4.4mm
Compliance
RoHS Status Non-RoHS Compliant
