MC100E016FN
RoHS
/
Package 28-LCC (J-Lead)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
J BEND QUAD Positive Edge Asynchronous Binary Counter IC 0C~85C 900MHz 5V 4.57mm
PDF
/
Buying Options
Total Price: USD $10.52
Unit Price: USD $10.5222
≥1 USD $10.5222
≥10 USD $8.6336
≥100 USD $8.3638
≥500 USD $8.094
≥1000 USD $7.8242
Inventory: 8603
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 28-LCC (J-Lead)
Surface Mount YES
Technical
Operating Temperature 0°C~85°C
Packaging Tube
Series 100E
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
Terminal Finish TIN LEAD
Additional Feature NECL MODE: VCC = 0V WITH VEE = -4.2V TO -5.7V
Technology ECL
Voltage - Supply 4.2V~5.7V
Terminal Position QUAD
Terminal Form J BEND
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 28
Qualification Status COMMERCIAL
Number of Elements 1
Supply Voltage-Max (Vsup) 5.7V
Supply Voltage-Min (Vsup) 4.2V
Reset Asynchronous
Direction Up
Output Characteristics OPEN-EMITTER
Logic Type Binary Counter
Number of Bits per Element 8
Trigger Type Positive Edge
Propagation Delay (tpd) 0.9 ns
fmax-Min 700 MHz
Count Rate 900MHz
Timing Synchronous
Dimensions
Height Seated (Max) 4.57mm
Compliance
RoHS Status Non-RoHS Compliant
