DM74ALS169BMX
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
GULL WING DUAL Positive Edge Synchronous Binary Counter IC 0C~70C 40MHz 5V 3.9mm
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.396
≥1 USD $0.396
Inventory: 7570
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 9.9mm
Technical
Timing Synchronous
Load/Preset Input YES
Count Rate 40MHz
Propagation Delay (tpd) 20 ns
Trigger Type Positive Edge
Number of Bits per Element 4
Logic Type Binary Counter
Direction Up, Down
Family ALS
Supply Voltage-Max (Vsup) 5.5V
Number of Elements 1
Reach Compliance Code unknown
Supply Voltage 5V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology TTL
Additional Feature TCO OUTPUT
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series 74ALS
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Surface Mount YES
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
