CD74HC161E
RoHS
/
Package 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
DUAL Negative Edge Asynchronous Synchronous Binary Counter IC -55C~125C 24MHz 5V 230ns
PDF
/
Buying Options
Total Price: USD $0.56
Unit Price: USD $0.5632
≥1 USD $0.5632
≥10 USD $0.49896
≥100 USD $0.468864
≥500 USD $0.382536
≥1000 USD $0.355309
≥3000 USD $0.302403
Inventory: 1095
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Timing Synchronous
Count Rate 24MHz
fmax-Min 35 MHz
Propagation Delay (tpd) 230 ns
Trigger Type Negative Edge
Number of Bits per Element 4
Logic Type Binary Counter
Direction Up
Family HC/UH
Reset Asynchronous
Supply Voltage-Min (Vsup) 2V
Supply Voltage-Max (Vsup) 6V
Number of Elements 1
Qualification Status Not Qualified
Supply Voltage 5V
Number of Functions 1
Terminal Position DUAL
Voltage - Supply 2V~6V
Technology CMOS
Additional Feature TCO OUTPUT
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Series 74HC
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Surface Mount NO
Package / Case 16-DIP (0.300, 7.62mm)
Mounting Type Through Hole
