MC14521BD
RoHS
/
Package 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
GULL WING TRUE DUAL Negative Edge Divide-by-2 IC -55C~125C 2000000Hz 18V 3.9mm
PDF
/
Buying Options
Total Price: USD $6
Unit Price: USD $6.0002
≥1 USD $6.0002
≥10 USD $4.9229
≥100 USD $4.76995
≥500 USD $4.61605
≥1000 USD $4.46215
Inventory: 11805
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Number of Pins 16
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Published 2009
Series 4000B
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Prescaler/Multivibrators
Technology CMOS
Voltage - Supply 3V~18V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 5V
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number 4521
Pin Count 16
Qualification Status Not Qualified
Operating Supply Voltage 18V
Number of Elements 1
Supply Voltage-Min (Vsup) 3V
Reset Asynchronous
Logic Type Divide-by-2
Output Polarity TRUE
Number of Bits per Element 24
Trigger Type Negative Edge
fmax-Min 6.5 MHz
Clock Edge Trigger Type Negative Edge
Max Frequency@Nom-Sup 2000000Hz
Count Rate 12MHz
Number of Data/Clock Inputs 1
Dimensions
Length 9.9mm
Width 3.9mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
