MC10EL33DTR2
RoHS
/
Package 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
Tape & Reel (TR) Obsolete e0 10EL33 divider circuit 2006 3mm -5.2V 33mA
PDF
/
Buying Options
Total Price: USD $130.64
Unit Price: USD $130.635649
≥1 USD $130.635649
≥10 USD $123.241177
≥100 USD $116.265257
≥500 USD $109.684211
≥1000 USD $103.475665
Inventory: 1184
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2006
Series 10EL
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Additional Feature NECL MODE: VCC = 0V WITH VEE = -4.2V TO -5.7V
Subcategory Prescaler/Multivibrators
Technology ECL
Voltage - Supply 4.2V~5.7V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.65mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number 10EL33
Pin Count 8
Qualification Status Not Qualified
Number of Elements 1
Supply Voltage-Max (Vsup) 5.7V
Power Supplies -5.2V
Supply Voltage-Min (Vsup) 4.2V
Reset Asynchronous
Logic Type Divide-by-4
Output Polarity COMPLEMENTARY
Trigger Type Positive, Negative
Power Supply Current-Max (ICC) 33mA
Count Rate 4.2GHz
Number of Data/Clock Inputs 1
Dimensions
Length 3mm
Width 3mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
