SN74LS684DW
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Comparators
Description
Lead Free Inverting TTL GULL WING Magnitude Comparator 0C~70C 5V 30ns @ 5V 45pF 45pF
PDF
/
Buying Options
Total Price: USD $4.24
Unit Price: USD $4.2416
≥1 USD $4.2416
Inventory: 8198
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 2.35mm
Width 7.5mm
Length 12.8mm
Height 2.65mm
Technical
Output Function A=B, A>B
Max Propagation Delay @ V, Max CL 30ns @ 5V, 45pF
Max I(ol) 0.024 A
Current - Output High, Low 400μA 24mA
Family LS
Turn On Delay Time 30 ns
Propagation Delay 30 ns
Number of Bits 8
Max Supply Current 65mA
Load Capacitance 45pF
Power Supplies 5V
Polarity Inverting
Operating Supply Voltage 5V
Pin Count 20
Output Active Low
Base Part Number 74LS684
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.85V~5.25V
Technology TTL
Subcategory Arithmetic Circuits
Additional Feature WITH A = B & A > B OUTPUTS
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Magnitude Comparator
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74LS
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Weight 500.709277mg
Number of Pins 20
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 6 Weeks
