SN74ALS518DWE4
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Comparators
Description
WITH PULL-UP RESISTORS ON Q INPUTS; CASCADABLE ACTIVE (Last Updated: 1week ago) Tube ALS digital comparator 17mA 33ns 7.5mm 50pF
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.073697
≥1 USD $1.073697
≥10 USD $0.415311
≥100 USD $0.401421
≥500 USD $0.394476
Inventory: 1578
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 2.35mm
Width 7.5mm
Length 12.8mm
Height 2.65mm
Technical
Output Function A=B
Max Propagation Delay @ V, Max CL 33ns @ 5V, 50pF
Max I(ol) 0.024 A
Current - Output High, Low 100μA 24mA
Family ALS
Turn On Delay Time 33 ns
Propagation Delay 33 ns
Number of Bits 8
Max Supply Current 17mA
Load Capacitance 50pF
Power Supplies 5V
Polarity Non-Inverting
Operating Supply Voltage 5V
Pin Count 20
Output Active High
Base Part Number 74ALS518
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology TTL
Subcategory Arithmetic Circuits
Additional Feature WITH PULL-UP RESISTORS ON Q INPUTS; CASCADABLE
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Identity Comparator
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74ALS
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Weight 500.709277mg
Number of Pins 20
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
