CD4063BPWRG4
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Comparators
Description
CMOS GULL WING Active High Not Qualified digital comparator -55C~125C 5/15V 350ns @ 15V 50pF 5mm
PDF
/
Inventory: 1467
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Number of Pins 16
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series 4000B
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Type Magnitude Comparator
Subcategory Arithmetic Circuits
Technology CMOS
Voltage - Supply 3V~18V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number CD4063
Output Active High
Pin Count 16
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 18V
Power Supplies 5/15V
Supply Voltage-Min (Vsup) 3V
Number of Bits 4
Propagation Delay 350 ns
Quiescent Current 100μA
Current - Output High, Low 4.2mA 4.2mA
Max Propagation Delay @ V, Max CL 350ns @ 15V, 50pF
Output Function AB
Dimensions
Height Seated (Max) 1.2mm
Length 5mm
Compliance
RoHS Status ROHS3 Compliant
