CD4063BM96
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Comparators
Description
ACTIVE (Last Updated: 6days ago) Tape & Reel (TR) e4 CD4063 digital comparator 4.2mA 4.2mA 350ns 3.91mm 50pF
PDF
/
Buying Options
Total Price: USD $0.41
Unit Price: USD $0.4136
≥1 USD $0.4136
≥10 USD $0.35288
≥100 USD $0.329824
≥500 USD $0.263824
≥1000 USD $0.244957
≥3000 USD $0.207275
Inventory: 6377
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Number of Pins 16
Weight 141.690917mg
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series 4000B
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Type Magnitude Comparator
Subcategory Arithmetic Circuits
Packing Method TR
Technology CMOS
Voltage - Supply 3V~18V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number CD4063
Output Active High
Pin Count 16
Qualification Status Not Qualified
Polarity Non-Inverting
Supply Voltage-Max (Vsup) 18V
Power Supplies 5/15V
Supply Voltage-Min (Vsup) 3V
Load Capacitance 50pF
Number of Bits 4
Propagation Delay 350 ns
Quiescent Current 100μA
Turn On Delay Time 350 ns
Current - Output High, Low 4.2mA 4.2mA
Max Propagation Delay @ V, Max CL 350ns @ 15V, 50pF
Prop. Delay@Nom-Sup 500 ns
Output Function AB
Power Supply Current-Max (ICC) 0.3mA
Dimensions
Height 1.75mm
Length 9.9mm
Width 3.91mm
Thickness 1.58mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
