M74HC85RM13TR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Comparators
Description
Tape & Reel (TR) HC/UH e4 M74HC85 digital comparator 5.2mA 5.2mA 31ns 3.9mm 50pF
PDF
/
Buying Options
Total Price: USD $5.36
Unit Price: USD $5.36465
≥1 USD $5.36465
≥10 USD $4.40135
≥100 USD $4.26455
≥500 USD $4.1268
≥1000 USD $3.98905
Inventory: 1414
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 9.9mm
Height Seated (Max) 1.75mm
Technical
Output Function AB
Max Propagation Delay @ V, Max CL 31ns @ 6V, 50pF
Current - Output High, Low 5.2mA 5.2mA
Family HC/UH
Turn On Delay Time 31 ns
Quiescent Current 4μA
Propagation Delay 31 ns
Number of Bits 4
Load Capacitance 50pF
Supply Voltage-Min (Vsup) 2V
Power Supplies 2/6V
Supply Voltage-Max (Vsup) 6V
Polarity Non-Inverting
Qualification Status Not Qualified
Pin Count 16
Output Active High
Base Part Number M74HC85
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Supply Voltage 4.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~6V
Technology CMOS
Subcategory Arithmetic Circuits
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Magnitude Comparator
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series 74HC
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Number of Pins 16
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
