CD74HCT85E
RoHS
/
Package 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Comparators
Description
CMOS Active High COMMERCIAL Magnitude Comparator Magnitude Comparator -55C~125C 5V 40ns @ 4.5V 50pF 50ns
PDF
/
Buying Options
Total Price: USD $0.72
Unit Price: USD $0.7216
≥1 USD $0.7216
Inventory: 728
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Output Function AB
Propagation Delay (tpd) 50 ns
Max Propagation Delay @ V, Max CL 40ns @ 4.5V, 50pF
Current - Output High, Low 4mA 4mA
Current - Quiescent (Iq) 8μA
Family HCT
Number of Bits 4
Supply Voltage-Max (Vsup) 5.5V
Qualification Status COMMERCIAL
JESD-30 Code R-PDIP-T16
Output Active High
Supply Voltage 5V
Number of Functions 1
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Type Magnitude Comparator
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Series 74HCT
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Surface Mount NO
Package / Case 16-DIP (0.300, 7.62mm)
Mounting Type Through Hole
