CD74HC85M
RoHS
/
Package 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Comparators
Description
Tube HC/UH R-PDSO-G16 74HC digital comparator 5.2mA 5.2mA 33ns @ 6V 50pF 5V -55C~125C
PDF
/
Buying Options
Total Price: USD $1.15
Unit Price: USD $1.1528
≥1 USD $1.1528
≥10 USD $1.03048
≥100 USD $0.97812
≥500 USD $0.80337
≥1000 USD $0.750983
Inventory: 597
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Output Function AB
Max Propagation Delay @ V, Max CL 33ns @ 6V, 50pF
Current - Output High, Low 5.2mA 5.2mA
Current - Quiescent (Iq) 8μA
Family HC/UH
Number of Bits 4
Supply Voltage-Min (Vsup) 2V
Supply Voltage-Max (Vsup) 6V
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G16
Output Active High
Supply Voltage 5V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~6V
Technology CMOS
Type Magnitude Comparator
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series 74HC
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Surface Mount YES
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
